We are from tunisia and searching for:
• A sewage submersible pump with flow ≥ 300mᵌ/h and HMT = 10 M (Quantity=03)
Materials :
– body pump : iron cast
– Shaft pump : AISI 304 or better
– Impeller pump : iron cast
Motor :
-3 phases
– IP 68
-Class H
– Shaft seal : mechanical seal
300mᵌ/h sewage submersible pump in Tunisia
NB: this pump must be equipped by lifting ring as well as resting feet and the motor by Thermal protection and order probe
• A Vertical pump(pump drained in water and motor on the surface as described in the attached plan) with flow = 162 mᵌ/h ± 5% and HMT = 50 m ± 5% (Quantity=04)
-Hydraulic pump ≥ 75%
-Power motor ≤ 45%
Motor :
-3 phases
– IP 55
-Class F
-IE2
vertical pump
Thank you for your inquiry about submersibe sewage pump and vertical pump, they are exactly what we are good at.
According to your request, we recommend sewage pump WQ200-300-10-22kw and vertical clean water pump SLG100-200(I).
There is quotation in the attachment, please check it.
Data specification of submersible sewage pump
Data specification of vertical pump
